SKU: CXL65-F
CXL65-F: Full Motion TV Wall Mount
Costco ITM. 8782021
Enjoy a perfect view from any angle
- Folds flat, extends out, tilts and turns
- Quick switch cable management arms
- Easy to install with on wall side to side positioning and screen levelling
- Fits 32-100″ TVs, VESA up to 600 mm x 400 mm
- Super strong, UL Certified up to 68 kg / 150 lb
- 25 year warranty
Scroll down for more information
-
Product Details
LOW PROFILE
6 cm
2.4 in.without adapters
LONG REACH
68 cm
26.8 in.
TURN
up to 90°
Strong and secure
Holds 32 – 100 in. (81 cm – 2.54 m) TVs weighing up to 68 kg / 150 lb. Compatible with VESA mounting sizes between 100 x 100 mm and 600 x 400 mm. Fixings are included for Wood Stud and Solid Walls (brick/concrete).Mount with confidence
Independently tested and certified by UL, and backed by AVF’s 25 Year Warranty.
Perfect for corners
The incredibly flexible arms allow you to position your TV directly in the corner of a room.
20° Screen Tilt
Avoid on-screen reflections and light glare, or get a better view when mounted higher on a wall. (12° down / 8° up)
Easy screen levelling
Tweak your screen without removing your TV from the wall.
Easy to Install and Adjust
With friendly, intuitive features, wall mounting your TV has never been easier
Pre-installed TV adapters
The industry’s first and only ‘out of the box’ solution that allows effortless fitting to TV VESA mounting holes in seconds.
Easy mount
Simply hook and hang in one movement.
Extra wide lateral shift
Just slide your TV and lock in the perfect position.
Quick-switch cable management
Adjust and hide cables with no need to remove covers.A perfect installation every time:
FAQ
-
What is VESA Size?
VESA refers to four circular threaded holes, positioned in a square/rectangular pattern on the back of most TVs. VESA ‘size’ is the distance in millimeters, between these holes. Measured horizontally, then vertically, from hole center to hole center.
-
Will my TV be secure?
You can install your TV with confidence – all our products are thoroughly tested to ensure their performance and safety, and still give you the manoeuvrability you need. Always ensure your TV is within the maximum weight listed for your mount.
-
What type of wall is this mount suitable for?
Fixings are included for Solid and Wood Stud walls.
-
What if I have a question or need advice?
If you have any questions or need something explaining, feel free to contact us – we’re always happy to help!
[email protected] / 1-800-667-0808
-
-
Video Guide
-
Specifications
Costco ITM. 8782021
Screen Size 32 – 100 in. (81 cm – 2.54 m)
Max Screen Weight 68 kg / 150 lb
Compatible VESA Sizes 100 x 100 mm, 200 x 100 mm, 200 x 200 mm, 200 x 300 mm, 300 x 100 mm, 300 x 200 mm, 300 x 250 mm, 300 x 300 mm, 400 x 200 mm, 400 x 300 mm, 400 x 350 mm, 400 x 400 mm, 400 x100 mm, 500 x 300 mm, 600 x 100 mm, 600 x 200 mm, 600 x 300 mm, 600 x 400 mm
Non-standard VESA Compatibility Any fixings from 300 mm to 600 mm wide and from 300 mm to 400 mm high
Suitable Wall Types Solid Wall (Brick/Concrete), Wood Stud Wall
Screen Tilt (Downward) up to 12°
Screen Tilt (Upward) up to 8°
Screen Turn up to 90°, Screen size dependant
Max Distance from Wall 68 cm / 26.8 in.
Min Distance from Wall 6 cm / 2.4 in.
On-Wall Levelling Yes
Cable Management Yes
Colour Black
UL Certified Yes
Warranty 25 Years
-
TV Height Calculator
-
Downloads
